As customers' demands
Hongguan
Galvanized Steel Flat Bar, a type of A36 hot rolled low carbon steel bar, is hot dipped with a zinc rich finish. Galvanized flat steel is a low-cost alternative to stainless steel, allowing for up to 30 years of rust-free protection while maintaining considerable strength and a durable hard surface coating. Metal Warehouse stocks many sizes in pre-cut lengths and full mill lengths, or we can hot dip virtually any size and quantity required for your welding or construction project.
Galvanized flats can be cut, machined or welded using methods commonly used for ordinary steel, but should be adequately ventilated to avoid fume inhalation during heating. The sawn ends of our pre-cut lengths are not galvanized and should be treated with a cold galvanizing compound to maintain protection after your project is complete. Any drilled or welded areas should also be treated.
| Product name | Galvanized Steel Flat Bar | ||
| Standard | ASTM, AISI, EN, DIN, JIS, GB | ||
| Grate | A36, S235JR, S355JR,St37-2, SS400, Q235, Q195,Q345 | ||
| Technique | hot rolled, slitted, round edge | ||
| Size | Width | Thickness | Length |
| 10-200mm | 1.5-30mm | 6m, 9m, 12m or customized | |
| Application | Construction/Shipbuilding/Machinery manufacturing/Steel structure | ||
| Features | 1. High quality | ||
| 2.High dimensional accuracy | |||
| 3. High utilization rate of material | |||
| 4. Saving cost price | |||
| Packing Details | 1. Iron sheet in both ends | ||
| 2.All wrapped packing with plastic woven bag | |||
| 3.Loose package | |||
| 4.As the requirement of customer. | |||
| Element | C | Cu | Fe | Mn | P | S |
| Percentage | 0.26 | 0.2 | 99 | 0.75 | 0.04 max | 0.05 max |
| Imperial | Metric | |
| Density | 0.282 lb/in3 | 7.8g/cc |
| Ultimate Tensile Strength | 58,000psi | 400 MPa |
| Yield Tensile Strength | 47,700psi | 315 MPa |
| Shear Strength | 43,500psi | 300 MPa |
| Melting Point | 2,590 - 2,670°F | 1,420 - 1,460°C |
| Hardness Brinell | 140 |
| Production Method | Hot Rolled |
Galvanized sheet
Galvanized Coil
Galvanized Pipe
Galvanized Rod
Galvanized Wire
(1)Fast delivery time, good quality and reasonable price
(2)We can process different finished products according to your requirements
(3)High production volume will shorten your waiting time
(4)Accept the buyer's specification
(5)Experienced R&D department
For more details about our products, please contact our sales for more information. Thank you for your visit
