As customers' demands
Hongguan
6061 is Aluminium a precipitation-hardened aluminum alloy containing magnesium and silicon as its primary alloying elements. It was originally known as "alloy 61S" and was developed in 1935. It has good mechanical properties, exhibits good weldability, and is very commonly extruded (its popularity is second only to 6063). It is one of the most common aluminum alloys for general use.
It is usually available in pre-tempered grades such as 6061-O (annealed), tempered grades such as 6061-T6 (solutionized and artificially aged) and 6061-T651 (solutionized, stress relieved tensile and artificially aged). Temperature: O T6 T651, etc.
| Produt Name | 6061 Aluminium Coil |
| Grade | 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. 2000 Series: 2014, 2024, etc. 3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc. 4000 Series: 4045, 4047, 4343, etc. 5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5251, 5454, 5754, 5A06, etc. 6000 Series: 6061, 6063, 6082, 6A02, etc. |
| Width | 2mm-2200mm |
| Thickness | 0.1mm-200mm |
| Length | As required |
| Standard | GB/T3190-2008,GB/T3880-2006,ASTM B209,JIS H4000-2006,etc |
| Temper | 0-H112,T3-T8, T351-851 |
| Surface | Mill, bright, polished, hair line, brush,sand blast, checkered,embossed, etching,etc |
| Shipment Time | Within 7-15 workdays after receiving deposit or L/C |
| Export Packing | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package. Suit for all kinds of transport,or as required |
| Free Sample | Send Inquiry to get Free Sample for evaluation |
| Elements | Cu | Mn | Mg | Zn | Cr | Ti | Si | Fe | Al |
| Contents | 0.14-0.5 | 0.15 | 0.8-1.2 | 0.25 | 0.04-0.35 | 0.15 | 0.4-0.8 | 0.7 | Rests |
| Mechanical Property | ||||||||
| Aluminum Coil | Grade | Normal Temper | Temper | Tensile Strength N/mm² | Yield Strength N/mm² | Elongation% | Brinell Hardness HB | |
| Plate | Bar | |||||||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu (2XXX) | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 | |
| Al-Mn (3XXX) | 3003 | O,H112,H | O | 110 | 40 | 30 | 37 | 28 |
| 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 | |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg (5XXX) | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| 5083 | O,H112,H | O | 290 | 145 | - | 20 | - | |
| Al-Mg-Si (6XXX) | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 | |
| Al-Zn-Mg (7XXX) | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 | |
Free samples
Factory direct sales, low price
Rich market forecast advice
Timely response
Advanced production line with solid production capacity.
Professional order system, complete operation.
Support third-party testing
