As customers' demands
Hongguan
5052 aluminum coil is an alloy consisting of 2.5% magnesium and 0.25% chromium. It is considered to have good machinability and weldability. It has moderate static and high fatigue strength. The corrosion resistance of this aluminum is very good, especially in the marine environment. This metal has excellent thermal conductivity and low density, as do other aluminum alloys. To harden 5052 aluminum, cold working can be used. Heat treatment cannot be used to obtain higher alloy strength.
The fatigue properties of this aluminum are excellent, with limits of 115 MPa at H32 tempering and 123 MPa at H34 tempering. The alloy content and strength of Grade 5052 aluminum is intermediate compared to other aluminum alloys. In slightly alkaline environments, alloy 5052 shows resistance levels. Its resistance to the marine environment is superior to that of the 5005 alloy, making it a more popular choice for marine applications.
| Produt Name | 5052 Aluminium Coil |
| Grade | 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. 2000 Series: 2014, 2024, etc. 3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc. 4000 Series: 4045, 4047, 4343, etc. 5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5251, 5454, 5754, 5A06, etc. 6000 Series: 6061, 6063, 6082, 6A02, etc. |
| Width | 2mm-2200mm |
| Thickness | 0.1mm-200mm |
| Length | As required |
| Standard | GB/T3190-2008,GB/T3880-2006,ASTM B209,JIS H4000-2006,etc |
| Temper | 0-H112,T3-T8, T351-851 |
| Surface | Mill, bright, polished, hair line, brush,sand blast, checkered,embossed, etching,etc |
| Shipment Time | Within 7-15 workdays after receiving deposit or L/C |
| Export Packing | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package. Suit for all kinds of transport,or as required |
| Free Sample | Send Inquiry to get Free Sample for evaluation |
| Mechanical Property | ||||||||
| Aluminum Coil | Grade | Normal Temper | Temper | Tensile Strength N/mm² | Yield Strength N/mm² | Elongation% | Brinell Hardness HB | |
| Plate | Bar | |||||||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu (2XXX) | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 | |
| Al-Mn (3XXX) | 3003 | O,H112,H | O | 110 | 40 | 30 | 37 | 28 |
| 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 | |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg (5XXX) | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| 5083 | O,H112,H | O | 290 | 145 | - | 20 | - | |
| Al-Mg-Si (6XXX) | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 | |
| Al-Zn-Mg (7XXX) | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 | |
Free samples
Factory direct sales, low price
Rich market forecast advice
Timely response
Advanced production line with solid production capacity.
Professional order system, complete operation.
Support third-party testing
