As customers' demands
Hongguan
Series 431 is a steel with good strength and toughness among martensitic stainless steels. It has good corrosion resistance to oxidizing acids, most organic acids and aqueous solutions of organic salts. It is generally used in the pumping of nitric and acetic acid, as well as shafts, piston channels, pumps and other parts of light industry, textile and other industries that require both toughness and corrosion resistance.
431 stainless steel containing nickel-chromium steel through heat treatment can obtain higher mechanical properties, its corrosion resistance is better than 410 steel and 430 steel. 431 stainless steel corresponds to China's 1Cr17Ni2, Japan's JIS SUS431.
| Sectional Dimension | Kg/m | Sectional Dimension | Kg/m |
| 100*50*5*7 | 9.54 | 344*354*16*16 | 131 |
| 100*100*6*8 | 17.2 | 346*174*6*9 | 41.8 |
| 125*60*6*8 | 13.3 | 350*175*7*11 | 50 |
| 125*125*6.5*9 | 23.8 | 344*348*10*16 | 115 |
| 148*100*6*9 | 21.4 | 350*350*12*19 | 137 |
| 150*75*5*7 | 14.3 | 388*402*15*15 | 141 |
| 150*150*7*10 | 31.9 | 390*300*10*16 | 107 |
| 175*90*5*8 | 18.2 | 394*398*11*18 | 147 |
| 175*175*7.5*11 | 40.3 | 400*150*8*13 | 55.8 |
| 194*150*6*9 | 31.2 | 396*199*7*11 | 56.7 |
| 198*99*4.5*7 | 18.5 | 400*200*8*13 | 66 |
| 200*100*5.5*8 | 21.7 | 400*400*13*21 | 172 |
| 200*200*8*12 | 50.5 | 400*408*21*21 | 197 |
| 200*204*12*12 | 72.28 | 414*405*18*28 | 233 |
| 244*175*7*11 | 44.1 | 440*300*11*18 | 124 |
| 244*252*11*11 | 64.4 | 446*199*7*11 | 66.7 |
| 248*124*5*8 | 25.8 | 450*200*9*14 | 76.5 |
| 250*125*6*9 | 29.7 | 482*300*11*15 | 115 |
| 250*250*9*14 | 72.4 | 488*300*11*18 | 129 |
| 250*255*14*14 | 82.2 | 496*199*9*14 | 79.5 |
| 294*200*8*12 | 57.3 | 500*200*10*16 | 89.6 |
| 300*150*6.5*9 | 37.3 | 582*300*12*17 | 137 |
| 294*302*12*12 | 85 | 588*300*12*20 | 151 |
| 300*300*10*15 | 94.5 | 596*199*10*15 | 95.1 |
| 300*305*15*15 | 106 | 600*200*11*17 | 106 |
| 338*351*13*13 | 106 | 700*300*13*24 | 185 |
| 340*250*9*14 | 79.7 |
Our company has a large long-term inventory to serve our customers faster and better.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 431 | Min. | / | / | / | / | / | 15 | / | 1.25 | / |
| Max. | 0.2 | 1 | 1 | 0.04 | 0.03 | 17 | 2.5 | |||
| Grade | Tensile Strength | Yield Strength | Elongation | Hardness | |
| (MPa) | 0.2% Proof (MPa) | (% in 50mm) | Rockwell B(HR B) | Brinell(HB) | |
| 431 | 635 | 440 | 20 | 220 | |
(1)Fast delivery time, good quality and reasonable price
(2) We can process different finished products according to your requirements
(3) High production capacity will shorten your waiting time
(4) Accepting buyer's specification
(5) Experienced R&D department
For more details about our products, please contact our sales for more information. Thank you for visiting
